SALIENT FEATURES

  • 100% Copper Winding
  • In Built with Thermal Over load Protector
  • Specially designed for wide voltage Operation
  • High grade cast iron stator body
  • Double sealed ball bearing.
  • Noiseless Operation.

TECHNICAL SPECIFICATION

  • Power Range: 0.5HP to 2.0HP
  • Speed: 2880 RPM
  • Versions: 1/3 Phase
  • Max. total head: Up to 41mtr
  • Max.flow rate: 4000 – 28000 LPH
  • Max.suction lift: 8 mtr
  • Class of insulation: B / E
  • Nominal size (Suc. & Del.): 25 x 25, 40 x 40, 50 x 50, 65 x 50, 80 x 65 & 80 x 80 mm

RANGE OF MODEL

ASP-110, ASP-444, ASP-755, ASP-1165 & ASP-1565/1577

Application

  • Domestic
  • Small Farming
  • Agriculture
  • Industrial water supply
  • Civil water supply application
